Equipment
Small- and Wide-Angle X-Ray Scattering (SAXS/WAXS) device
Image: Yves Carstensen (Small- and Wide-Angle X-Ray Scattering (SAXS/WAXS) device)
Europäischer Fonds für regionale Entwicklung (EFRE)
Picture: Europäischer Fonds für regionale Entwicklung (EFRE) (EFRE)This new SAXS/WAXS device was funded by the Europäischer Fonds für regionale Entwicklung (EFRE) of the European Union as part of the REACT-EU program
This device will ideally complement existing methods for nanomaterial characterization. Thus, a measurement of SAXS and WAXS on the same sample and position can be performed simultaneously over an angular range of up to 2Θ = 75°, which has not been feasible so far. In addition, the repertoire of possible sample types (gels and pastes) and the usable temperature range (approx. -150 to +350 °C) are significantly expanded, and an automated sample changer for solid and liquid samples is integrated to enable high-throughput analyses.
Laboratories
Image: Felix H. Schacher
MBraun Glovebox UNIlab Pro Eco
Image: Felix H. Schacher
Size Exclusion Chromatography (SEC) / CHCl3 (RI + UV)
Image: Felix H. Schacher
THF-SEC
Image: Felix H. Schacher
Dynamic / Static Light Scattering: ALV Laser CGS3 Goniometer
Image: Felix H. Schacher
Cary 60 UV/Vis Spectrometer incl. additional 200W Xenon Source and Thermostat
Image: Felix H. Schacher
Perkin-Elmer TGA 8000 connected to ATR-IR Spectroscopy, incl. high temperature ATR unit (solid/liquid)
Image: Felix H. Schacher
SWAXS
Image: Felix H. Schacher
Spetec FlowBox FBS 56
Image: Felix H. Schacher
UVA-Cube 250W Lamp (Dr. Hönle AG)
Image: Felix H. Schacher
Erichsen Coatmaster 510
Image: Felix H. Schacher
Ultrasound Processor: Sonics VibraCell VC505
Image: Felix H. Schacher
Powertome XL Ultramikrotome incl. Camera & Cryo-Chamber
Image: Felix H. Schacher
Plas-Labs THC-#890 with Drying Train - Temperature & Humidity Controlled Environmental Chamber
Image: Felix H. Schacher
